Portable Assembly Stage Floors
Code: Sân khấu cơ bản
Status: Stocking
- Unit price: 1,500,000 - 2,200,000 VND/m2
- Model: Quick Assembly Stage
- Origin: Vietnam
- Brand: Viettruss
- Width: Optional
- Depth: Optional
- Height: Fixed or up or down
- Board material: MDF covered with film
- Frame Material: Aluminum Alloy T6061-T6
- Connection type: Connector flower star fruit
- 1 year warranty
✅ SPECIFICATIONS OF MOBILE ASSEMBLY STAGE
Application | Event organization, hall stage, wedding party |
Alloy material | Aluminum Alloy 6061-T6/6082-T6 . Aluminum Alloy |
Connection type | Connector mount |
Module size | Total 1228* depth1228mm |
Structure | Connector Profile Frame |
Maximum payload | 300kg/module |
Floor wood type | MDF covered with waterproof film |
Wood thickness | 18mm |
Tonnage | 300kg/module |
Weight | 23kg/module |

.jpg)
✅ STATE FRAME FRAME MATERIAL DURABILITY SPECIFICATIONS
Mass properties of V1MDF-1228mm Configuration: Default Coordinate system: -- default -- Density = 2700.000 kilograms per cubic meter Mass = 23.215 kilograms Volume = 0.005 cubic meters Surface area = 3,526 square meters Center of mass: ( meters ) X = 0.000 Y = 0.000 Z = -0.750 Principal axes of inertia and principal moments of inertia: ( kilograms * square meters ) Taken at the center of mass. Ix = ( 0.000, 0.000, 1,000) Px = 0.350 Iy = ( 0.707, -0.707, 0.000) Py = 3.178 Iz = ( 0.707, 0.707, 0.000) Pz = 3.179 Moments of inertia: ( kilograms * square meters ) Taken at the center of mass and aligned with the output coordinate system. Lxx = 3.178 Lxy = 0.000 Lxz = 0.000 Lyx = 0.000 Lyy = 3.178 Lyz = 0.000 Lzx = 0.000 Lzy = 0.000 Lzz = 0.350 Moments of inertia: ( kilograms * square meters ) Taken at the output coordinate system. Ixx = 10,612 Ixy = 0.
