KYSTAR U3 . Image Processor

The Kystar U3 led screen image processor product line is being well received by many brothers in the technical world. The following article Hoang Sa Viet will introduce to customers the specific functional features of this Processor LS3 series.

✅ Specification for Kystar U3 Led screen image processor

✔ Kystar U3 image processor overview

Kystar U3 image processor or known another name as Led display controller Kystar U3 is a specialized processor applied CPT + FST coupling technology specially designed for LED display screen approx. Small way to ensure the uniformity and synchronization of concatenation. The SKYSTAR U3 Image Processor is a high-end video processing device specially for LED large screen, conference room, studio and other markets. Processor Kystar U3 adopts industry-leading design technology and meets international and industry standards.

In full machine duplication mode, 2.6 million pixels are customized to be loaded, and the splicing maximum load is 2560 x 1536, the Kystar U3 image processor should cover most field requirements. KS910Plus has multiple monitoring modes, switching modes, complete backup, safe and reliable.

✔ Kystar U3 Image Processor Functional Features

• Support custom 2.6 million pixel load output
• The max load of splicing mode is 2560 x 1536 @ 60HZ.
• Arbitrary layout of three images, easily complete centralized control of the stage main screen and sub monitor
• Support signal echo, real-time viewing of input and output signals through software
• Supports 4K UHD signal processing
• Multi-group editable global text overlay
• Supports seamless switching of signals and modes, providing more than ten transition effects
• Support dimming brightness, adjust image transparency and edge appearance
• Support multi-level input signal backup and multi-stage synchronous output
• Block and display any part of the signal source
• Custom EDID
• Save 32 scenario modes, one-click call
• One-click/static black screen support
• Built-in two LED sending cards

✔ Kystar U3 . Led display controller input/output interface

• Input: DVI*1, HDMI*2, SDI*1, VGA*2, CVBS*2
• EX Input HDMI DVI*2, HDMI*2, CVBS*2, HDMI-SDI*1 (including SDI*1 loop), SDI*2 (including SDILOOP*2), HDMI-4K*1
• Output: DVI*2, Monitor*1, DVI-LOOP*1
• Control port RS-232 (DB-9)*1, RJ-45*2

✔ The loading capacity of the Led screen image processor Kystar U3

• Custom 2.6 million copy mode
• Maximum Width 3840
• Maximum height: 1920
• Splice mode: 2560 X 1536

Above are the features and functions of the Kystar U3 Led screen image processor product line . To learn more about this processor product , please contact Hoang Sa Viet's hotline 0985 999 345 for enthusiastic support. Thank you!
